Pendant luminaire

Torino

When you are looking for a lighting solution that will make its mark while still remaining unobtrusive, then Torino LED is the perfect choice. Its elliptical design ensures an even spread of light across the diffuser and throughout the space. Highly efficient thanks to cutting-edge LED technology. Not only a top choice for architects. This easy-to-mount, low-maintenance luminaire is also popular with electrical installers and facility managers.



Features Features
  • Elliptical diffuser, timeless design
  • Direct-indirect light emission, omni-directional
  • Up to UGR <16
  • Excellent light quality, extremely even spread of light across the whole surface
  • three-dimensional LED boards for extremely good homogenous omnidirectional illumination
  • Seamless surface
  • Minimum maintenance costs and additional expenditure due to sealed luminaire housing
  • Design by Andreas Tobler
  • Colour temperature can be adjusted individually with the Tunable White technology
Specifications Specifications
  • Diameters 450, 600, 800 mm
  • Two lengths of pendant tube per diameter
  • Opal diffuser in synthetic material
  • Operating unit integrated
  • Suitable for emergency lighting (DC-compatible)
  • Available with emergency unit
  • Pendant tube with ball and socket joint, self-adjusting up to 20°
  • Pendant tube 1 m long as standard; can be shortened on site

Technical data Technical data
  • System power: 15 W / 28 W / 24 W / 52 W / 54 W / 60 W / 45 W / 76 W
  • Luminous flux of luminaire: 2450 lm / 2350 lm / 4100 lm / 3950 lm / 3850 lm / 3700 lm / 7700 lm / 7400 lm / 8600 lm / 7600 lm / 7300 lm / 12200 lm / 11700 lm
  • Colour temperature: 4000 K / 3000 K / 6500 K
  • Colour Rendering Index: CRI >80
  • Maintained luminous flux: L80 50'000 h
  • Protection class: Protection class I
  • Ingress Protection (IP): IP40
Fields of application Fields of application
  • Office & Education
    classrooms, meeting rooms, foyers and lobbies
  • Retail & Hospitality
    hotels, reception areas, corridors, circulation zones, retail spaces, shopping malls
Version
0 Article
Diameter
450 mm
600 mm
800 mm
System power
15 W
24 W
28 W
45 W
52 W
54 W
60 W
76 W
Colour temperature
3000 K warm white
4000 K neutral white
6500 K Tunable White
Pendant Length
1020 mm
1055 mm
1100 mm
3120 mm
3155 mm
3200 mm
