Ceiling mounted luminaire

Solo Slim Office

Harmonious in both form and illumination: The elegant Solo Slim can be integrated in any architecture thanks to its round shape and slender frame height. The jointless surface and perfectly manufactured housing make Solo Slim an aesthetic and highly efficient light object suitable for office use.



Features Features
  • Height of frame only 53 mm, white
  • One-piece look aluminium housing, first-class workmanship makes for seamless surface
  • Extremely even spread of light across the opal diffuser or microprismatic C-LED optics, suitable for application in offices
  • Recessed ceiling luminaire with or without trim or especially recessed in concrete
  • Ceiling mounted luminaire optional halo effect through indirect component (8 %)
  • Pendant luminaire direct-indirect light emission (61 %/39 %)
  • Available with MyLights Tunable – enabling the colour temperature to be adjusted to align with daylight conditions
  • LED board and optics replaceable
  • Colour temperature can be adjusted individually with the Tunable White technology
Specifications Specifications
  • Up to 4 diameters depending on the mounting type: ca. 400 mm, 500 mm, 650 mm, 950 mm
  • Standard-compliant C-LED optics according to EN 12464-1 with Glare control: up to UGR < 16 and maximum luminance up to Lmax ≤ 3000 cd/m2
  • Operating unit integrated
  • Dimmable digital DALI
  • Suitable for emergency lighting (DC-compatible)
  • Available with emergency unit
  • Pendant tube 1 m long as standard; can be shortened on site
  • Other types of pendant possible thanks to accessories (3 m can be shortened on site, surface mounted and pendant luminaire)
  • IP44 kit optional

Technical data Technical data
  • System power: 8 W / 15 W / 14 W / 25 W / 33 W / 26 W / 39 W / 56 W / 75 W
  • Luminous flux of luminaire: 1150 lm / 1060 lm / 2150 lm / 1980 lm / 2200 lm / 2050 lm / 3700 lm / 3450 lm / 4350 lm / 4050 lm / 3750 lm / 5800 lm / 5300 lm / 8900 lm / 8200 lm / 11900 lm / 11000 lm
  • Colour temperature: 4000 K / 3000 K / 6500 K
  • Colour Rendering Index: CRI >80
  • Maintained luminous flux: L80 50'000 h
  • Protection class: Protection class I
  • Ingress Protection (IP): IP40
Fields of application Fields of application
  • Office & Education
    reception rooms, offices, open-plan offices, conference rooms, cafeterias, classrooms, libraries, corridors
  • Retail & Hospitality
    care homes
  • Industry
    hospitals
Version
0 Article
PROH_8039_TK.jpg Without indirect lighting
PROH_8040_TK.jpg With indirect lighting
Diameter
430 mm
530 mm
680 mm
980 mm
System power
8 W
14 W
15 W
25 W
26 W
33 W
39 W
56 W
75 W
Colour / Finish
silver
white
Colour temperature
3000 K warm white
4000 K neutral white
6500 K Tunable White
Light control
DALI
MyLights Remote Casambi
emergency unit
without emergency unit
